CPU: Motorola 68000 @ 8Mhz
RAM: 512KB
Sound: Yamaha YM2149
Drive: single-sided 3˝" floppy disk drive
Ports: TV out (on FM models), MIDI In/Out, RS-232, Printer, Monitor
(RGB and Mono), Extra Disk drive port, Joystick and Mouse ports
Operating System: TOS (Tramiel Operating System) with the GEM
(Graphical Environment Manager) GUI
Display modes: 320×200 (16 colour), 640×200 (4 colour), 640×400
(mono), palette of 512 colours
Very early machines included the OS on a floppy disk, but this was
quickly replaced with ROM versions instead. Another early addition
(after about 6 months) was an RF Modulator that allowed the machine
to be hooked to a colour TV when run in it low resolution mode.
These models were known as the 520 STm, although the m did not
appear on the label. |
